Lifting Lug Weld-0.5Ton
½-Ton Lifting Lug Capacity
-
0° to 20° Angle: The maximum safe working load is 1000 lbs when the force is applied within 20 degrees of vertical.
-
21° to 30° Angle: The rated capacity decreases to 750 lbs.
-
31° to 45° Angle: The rated capacity is further reduced to 500 lbs.
-
>45° Angle: Do not use. Lifting at any angle exceeding 45 degrees is prohibited.
Note: The structure to which the lug is attached must be strong and rigid enough to support the load. Additional reinforcement or gussets may be necessary to prevent damage
